Solar Solutions for OfficeBuildings: Cut Costs,Improve Energy Efficiency
This white paper provides clear solar energy management solutions forcommercial office buildings and multi-tenant office complexes. Itaddresses core needs such as office operating costs, power stability, andenhancing building value.
Current Energy Challengesfor Office Buildings
High Electricity Costs
Air conditioning, lighting, and elevators consume large amounts of electricity. leading to high energy bills.
Tenant SustainabilityDemands
Power outages affect normaloperations and tenant experience, reducing buildingattractiveness.
High Electricity Costs
Corporate tenants increasingly prioritize eco friendly office spaces.
BuildingCompetitiveness
Energy efficiency has become a key selling point inthe competitive office market.
Solar Energy Solutions for Office Buildings
Cost Savings
Solar systems can effectively reduceelectricity expenses by over 5o%,making office buildings more competitive in the long-term rental market.
Stable Power Supply
Energy storage systems provide backup power during outages, ensuring continuous operation ofcritical equipment like elevators and air conditioning.
Enhanced Building Value
Solar-equipped buildings are more attractive to tenants and can meetinternational green building standardslike LEED certification.
Customized SolarSolutions
System Design
Tailored solar systems based on building area, power load,and tenant needs, including rooftop or parking lot solarpanels, energy storage systems, and inverters for powerstability.
Installation and Integration
Seamless integration of solar systems with existing powerinfrastructure.
Remote Monitoringand Management
Real-time monitoring of power usage through smart systems for optimized energy management.
TANFON TSP-150KW solar system
Solar panel
| TFD600W half cell PERC solar panel(LonGi N type TopCon Solar Cell) Vmp: 43.44V Voc: 51.54V Imp: 13.81A Isc:14.50A Efficiency: 23.22% Size: 2279*1134*30MM Strong anti-cracking advantage 25 years product warranty Connect way :each 14pcs in series. |
PV combiner
| Model:H5T-384v Multiple PV strings inputs Simplify wiring between PV array and controller, protections to controller , Wide range of DC input voltage max circuit voltage: 1000V Reliable thunderstorm& surge protection warranty:3 years |
Mppt Controller
| Real MPPT PV controller model:384V/100A MPPT efficiency; >99.9%, Max input voltage :800V various protection functions; Size:500*384*228mm ,weight:27KG warranty:3years |
Three phase inverter
| Safety IGBT inverter :T150KW384VDC DC voltage :360V-438V Ouput voltage:380v/415v 50hz or 60HZ German 5S technology IGBT Stronger for motor loads 360° guarantee Two-way flame retardant protection Same as government project quality . Size:1200*897*1580mm weight:1.5T With IOT extend warranty:5 years |
Lithium battery
| Model number: TFES-S384560 Voltage: 384V Capacity: 560AH Nominal capacity: 215KWh safety discharge current:600A Cycle life: 6000 Material: BYD battery cells 710*850*1900mm*2pcs weight:1336kg*2pcs Latest technical advantages:Input and output are completely isolated, no leakage, constant current and constant voltage output function,Lightning protection, safe and reliable. With IOT extend warranty:10 years |
Battery cabinet
| Convergence cabinet The electricity from the two lithium batteries passes through the fuse and the switch controls the power supply of the circuit. |
Panel rack
| Slope Rooftop /Flat rooftop/ground wind load:55m/s,snow load:1.5kn/m2 structure:Anodized Aluminum+stainless steel, Angle adjustable (other type of rack can be customized as per client’s requirement ) |
Cables
| 1)cabinet to inverter cable 95mm2 *5M*2pcs 2)Battery to cabinet cable 50mm2*3M*4pcs 3)PV combiner to MPPT cable 25mm2*5M*4pcs 4)4mm2 PV cable 800M, (black+ red) 5)1set MC4 Tools 6)12sets cable terminals and MC4 |
Success Stories
Kenya Office Building Project
80KW solar + 150KWh storagesystem.Results:40%electricity savings, 20%increase in tenant renewalrate. Client feedback: "Thesolar system attracted moreeco-conscious corporatetenants, greatly enhancing ourbuilding's value."
South African Shared Office Space
1ooKW solar + storage system.Achieved continuous powersupply,significantly reducingthe impact of outages ontenant businesses while savingon electricity costs.
After-Sales Service and Guarantees
Quality Assurance
Reliable service guarantee with a quality depositmechanism to ensure system performance.
Regular Maintenance
Professional team conducts periodic on-site inspectionsto ensure efficient system operation.
5 years of free online operation
Our engineers regularly help you check the power BROCISTEND FINAL REPORT generation data of solar panels, the charge and discharge data of lithium batteries, and the output data of inverters. If you have any questions, we will provide online guidance and communication.
FrequentlyAsked Questions
System Capacity
Can the solar system meetthe entire building's powerneeds?
Structural Impact
Will installing solar panels affect the roof structure?
Installation Process
Is a power outage necessary How will tenants be affected during system installation?
Tenant Impact
How will tenants be affected during power outages?
Take the Next StepTowards SustainableOffice Buildings
Implementing solar solutions in your office building can significantly
reduce operating costs, improve energy stability, and enhance your
property’s value. Our customized approach ensures that your specific
needs are met, while our comprehensive after-sales service provides
peace of mind.
Ready to transform your office building with solar energy? Contact us
today for a personalized consultation and discover how we can help you
achieve your sustainability and efficiency goals.
